General purpose connector kit provides components required to connect most hydraulic type fuel injectors to nozzle testing equipment. Connectors are double-threaded (Left and Right Hand) permitting quick connect/disconnecting to injectors. Provided with a handy plastic carrying case for storage of connectors, adapters, and fittings.
Contents include:
(1) Connector Nut, M12 x 1.5 x 1/2 - 20LH (part # 4011)
(2) Connector Nut, M14 x 1.5 x 1/2 - 20LH (part # 4012)
(1) Connector Nut, M18 x 1.5 x 1/2 - 20LH (part # 4013)
(1) Connector Nut, 9/16 x 18NF x 1/2 - 20LH (part # 4014)
(1) Connector Nut, 5/8 - 18NF x 1/2 - 20LH (part # 4015)
(1) Adapter, Ermeto, 1/2-20LH 60 Deg. X 1/2-20LH (part # 4021)
(1) Rigid Connector, 9" Long (part # 4224)
Carrying Case (part # 300-2001)
Application:
1. General Purpose
2. J.I. Case
3. Continental
4. Ford Tractor
5. Massey Ferguson
6. Minnesota-Moline
7. Perkins
8. Peter
9. Mack
10. John Deere
11. Caterpillar
12. Hercules
